Oertzen H.B 250
Hot water generator for expanding cold water high-pressure cleaners
Max. flow rate 1,260 l/h
Max. working pressure 230 bar
Standard voltage 230 V
Leaves no high-pressure cleaner cold
In some situations, high-pressure cleaning with hot water is necessary or at least more effective. The Hotbox is our solution for HP cleaners without a hot water function: The hot water generator can be easily connected to high-pressure cleaners with a working pressure of up to 230 bar.
- Boiler with heating coil
- Maximum water temperature: 150 °C
- Includes 4-metre electric cable with safety plug
- Optionally available flow divider kit for coupling two Hotboxes
Motor and pump performance
- 230 V/1~50 Hz
- Working pressure max. 230 bar
Features
- boiler with heating coil, vertical burner system
- thermostat
- fuel-oil filter
- frame powder coated, hood PE
Standard equipment
- fuel-oil jerrycan 20 l / 5.3 gal, interchangeable
- 2 m / 6.6 ft high pressure hose
- 4 m / 13 ft electric cable with safety plug
Application range
- container cleaning
- road cleaning
- paint removal
- wall cleaning
- facade cleaning
- grafitty removal
- hot water cleaning
- high pressure cleaning
- industrial cleaning
- duct relining
- commercial cleaning
- traffic sign cleaning
Flow rate max.
10 – 21 l/min, 600 –1,260 l/h
Incoming water pressure
min. 20 bar
Working pressure max.
230 bar
Water temperature max.
50–150 °C / ΔT 75 °C
Heating power
80,000 kcal
Standard voltage
230 V / 1~50 Hz
Dimensions (frame: L x W x H)
690 x 700 x 900 mm
Weight (net)
103 kg
Fuel consumption
8,3 kg/h
Fuel
diesel / fuel oil
Sound power level
98 dB max.
Order number
710.000.144
Please notice
technical data are subject to alterations
